Architec 400 is an extra heavy duty fabric at over 400gsm, designed for large commercial projects with large structures and spans. The fabric incorporates the latest in Ultra Violet (UV) stabilizers and comes with a 15 year UV warranty, the best in the industry. These new UV stabilizers also provide improved colour consistency, colourfastness and durability.

Architec 400® contains no flat tape. It is made from a combination of monofilament yarn and our proprietary Ovalon monofilament yarn. Ovalon provides high strength and minimal stretch in both the Weft and Warp direction of the stitch pattern, maintaining tension. It also offers over 90% UV protection.

With Ovalon you get the strength of monofilament yarns combined with the UV protection of tape.

PRODUCT FEATURES

• Strong Lockstitch construction
• Built for high loading and large spans
• UV stabilised with monofilament and tape
• Best biaxial behaviour in its category
• Industry leading 15 year UV warranty
• Over 90% UV protection
• Heat set for stability and easy fabrication
• Strong virgin HDPE will not absorb moisture
• Easy to clean
• 100% recyclable

Available in:

• 3.00 x 50m centre folded rolls
• 3.80 x 50m triple folded or straight rolls

Average weight: 400 gsm

This warranty does not cover, and Polyfab is not liable for, deterioration of fabric occurring due to any of the following circumstances:

• Exposure to pollution, chemicals, solvents, halogens, cleaning agents or other substances that are harmful to the performance of the fabric.
• Faulty installation of the fabric or faulty design or manufacture of any structure to which the fabric is attached.
• Damage caused by mechanical wear and tear, abrasion or rubbing on frame work and cabling, as a result of excessive and continual wind flap or storm damage. The fabrics UV warranties do not pertain to such damage caused by storms, hailstorms, earthquakes, mechanical damage caused by birds or other animals, fire, lightening etc. Again this is not an exhaustive list and it is for reference only.
• During installation, The Polyfab Australia shadecloth should not be subject to “pre-stressed” loading in excess of 20%.
• Wind flap is the major cause of pre-mature breakdown in any quality outdoor fabric. It is therefore critical that the fabric be installed under tension and maintained in a tensioned condition. (refer Instillation guidelines). Fabric that is allowed to flap can and will be abraded by structural poles and support wires, this is deemed to be mechanical breakdown and is not covered by the UV warranty.
• Fabric should be supported by using appropriate strength poles and footings as determined by a professional structural engineer, and fabricated and installed by a qualified contractor in accordance with local building codes.
• Improper use of the fabric or use contrary to the specifications for the fabric.
• Technical testing information supplied by Polyfab Australia is sourced from third party testing authorities, and tolerances may vary by as much as 10%.
• Outdoor fabrics are subject to harsh conditions and degradation over time is to be expected. The fabric is supported with a 15 year UV warranty. During this period the fabric will remain serviceable and fit for purpose. Colour fading is normal over time. Colours containing red and yellow pigments have a tendency to fade more than others. This is not a loss of strength caused by UV breakdown and is not covered by the product warranty.
• Minor colour variation from fabric samples.
• Minor visual imperfection due to the manufacturing processes.
• The negligent act or omission of any person.
• Misuse, neglect or abuse of the fabric.
• The manufacturer reserves the right to alter or modify product specifications and colours without notice and assumes no obligation or liability for the suitability and use of its products other than those applications intended by the manufacturer.
